SECTION 5—OPERATING INSTRUCTIONS
Platinum
™
Series 22 Part No 1118353
Front Panel Indicators - Units without
SensO
2
NOTE:Forthisprocedure,refertoFIGURE5.8.
FIGURE 5.8 Front Panel Indicators - Units without SensO2
Initial Startup of the Concentrator
NOTE:Concentratormaybeusedduringtheinitialstartwarm‐up
time(approximately30min).O
2
puritywillbuildtoamaximum
duringthisperiod.
LABEL
SYMBOL
STATUS INDICATOR LIGHTS
(LED)
SYSTEM OKAY GREEN Indicator Light
SYSTEM FAILURE RED Indicator light
Continuous Audible Alarm
Sieve-GARD™Compressor
Shutdown
Call a qualified technician. Switch
to a back-up supply of oxygen
immediately.
Call Supplier
Normal
RED
GREEN
Auto Shut - Down
Use Backup
I/O
I/O
