Invacare IRC10LX User Manual

SECTION 5—OPERATING INSTRUCTIONS
Platinum
™
Series 18 Part No 1118353
FIGURE 5.2 Humidifier Compartment
3. Removethefilteraccessdoorlocatedonthesideofthe
concentrator.Insertaflatheadscrewdriverintheplate
grooveonthetopedgeofthefilteraccessdoorandgently
prythefilteraccessdooropen.RefertoDetail“A ” in
FIGURE5.3.
4. Thehumidifieradapterisnexttotheinletfilter.Pullup
andremovethehumidifierbottleadapter.RefertoDetail
“B”inFIGURE5.3.
5. Attachittothehumidifierbyturningthewingnutonthe
humidifierbottlecounterclockwiseuntilitissecurely
fastened.RefertoDetail“C”inFIGURE5.3.
6. Placethehumidifierbottleinthehumidifiercompartment.
FIGURE 5.3 Attaching the Humidifier Bottle Adapter
Humidifier Bottle
DETAIL
“A”
Plate Groove (Insert
Flat Head Screwdriver
Here)
Filter
Access
Door
DETAIL
“B”
Humidifier
Bottle
Adapter
Humidifier Bottle
Adapter
Filter
Access
Door
DETAIL “C”
