SECTION 5—CABINET
Part No 1148070 23 Perfecto
2
™
SECTION 5—CABINET
Removing Cabinet
 DANGER
Topreventelectricalshock,ALWAYSdisconnectconcentratorfromelectricaloutlet
beforeservicing.
NOTE:Forthisprocedure,refertoFIGURE 5.1.
1. Unplugunit.
2. Removethefourmountingscrewsthatsecurecabinetassemblytothebaseassembly.
3. Liftthecabinetstraightup.
NOTE:Whenrequired,vacuuminsideofthecabinetandexposedfoaminsulation.
4. Tore‐installcabinet,reverseSTEPS2‐3.
L
FIGURE 5.1 Removing Cabinet
Cabinet Assembly
Mounting
Screws
Base Assembly
Mounting
Screws
