Invacare Pronto M91 Owner's Manual

SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS
Pronto® M91™ with SureStep® 22 Part No 1141450
Pinch Points
 WARNING
Pinch point may occur when returning
the tilted seat to the full upright
position. Make sure the hands and body
of the occupant, attendants and
bystanders are clear of all pinch points
before lowering seat (FIGURE 3.2).
DO NOT store or place items under the
seat.
NOTE:Forthisprocedure,referto
FIGURE 3.2andFIGURE 3.3.
FIGURE 3.2 Pinch Points
 WARNING
Pinch point may occur when adjusting the arm angle position (Detail “A”).
Pinch point may occur when rotating the footboard assembly (Detail “B”).
FIGURE 3.3 Pinch Points
A Note to Wheelchair Assistants
Whenassistancetothewheelchairuserisrequired,remembertousegoodbody
mechanics.Keepyourbackstraightandbendyourkneeswhenevertiltingwheelchairor
traversingcurbsorotherimpediments.
Also,beawareofdetachablepartssuchasarmsorlegrests.ThesemustNEVERbeused
tomovethewheelchair
orasliftingsupports,astheymaybeinadvertentlyreleased,
resultinginpossibleinjurytotheuserand/orassistant(s).
Whenlearninganewassistancetechnique,haveanexperiencedassistanthelpyoubefore
attemptingitalone.
Pinch
Point
Pinch
Point
Pinch Point
DETAIL “A”
DETAIL “B”

Invacare Pronto M91 Specifications

Power and Performance

maximum speed	6.5 mph / 4.5 mph
incline capability	9˚
weight capacity	300 lb. (400 lb. option)

Wheel and Caster Sizes

front casters	6" x 2"
drive wheels	14" x 3"
rear casters	6" x 2"

Weight and Dimensions

length with footboard up	39"
length with footboard down	40" - 42"
width excluding joystick	25.9"
height	37" - 48"
seat width	18" - 22"
seat depth	16" - 20"
overall height	37" - 40"
back height	18"
seat-to-floor height	21" - 23"
weight with batteries	273 lb.
weight without batteries	199 lb.
wheelchair mass	275 lb.
turning radius front	19.5"
turning radius rear	21.5"
ground clearance	3.25"
