Matrix Mono
Part 2 - Engineering Data
Engin
eerin
g
Data
Matrix Mono
36
Matrix Mono Engineering Data Book
9. Power Cord Connecon of group control system
Use a dedicated power supply for the indoor unit that is different from the power supply for the outdoor unit.
Use the same power supply, circuit breaker and leakage protecve device for the indoor units connected to the same
outdoor unit.
+
Power cord
Insulation tube
Circular wiring
terminal
: Copper wi
re
Proper power wiring connections
Power Supply
Circuit Breaker
Manual swtich
Wire Distribution Box
......
Matrix Mono
37
Part 2 - Engineering Data
5 Capacy Tables
5.1 Heang Capacity Tables (Test standard：EN14511)
Table 2-5.1: Heang capacity for ATM(H)04S(3)
Maximum
DB
LWT
25 30 35 40 45 50 55 60 65
HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP
-25 2.05 1.18 1.74 1.80 1.22 1.48 1.71 1.32 1.29 1.53 1.30 1.18 1.37 1.25 1.10 / / / / / / / / / / / /
-20 3.09 1.31 2.36 2.83 1.56 1.82 2.44 1.70 1.43 2.17 1.74 1.24 1.98 1.75 1.13 1.85 1.75 1.06 1.56 1.59 0.98 / / / / / /
-15 3.60 1.19 3.03 3.41 1.22 2.78 3.25 1.36 2.39 2.93 1.49 1.97 2.50 1.60 1.56 2.20 1.68 1.31 1.84 1.56 1.18 1.73 1.68 1.03 / / /
-10
4.17 1.22 3.40 4.49 1.38 3.25 4.34 1.52 2.85 4.02 1.65 2.43 3.59 1.77 2.02 3.28 1.81 1.81 2.63 1.68 1.56 2.81 1.80 1.56
/ / /
-7
4.92 1.33 3.69 5.14 1.46 3.52 4.99 1.60 3.11 4.67 1.73 2.70 4.54 1.98 2.29 4.41 2.12 2.08 4.28 2.34 1.83 3.56 1.94 1.84
/ / /
-5
4.99 1.24 4.03 5.18 1.39 3.72 5.02 1.53 3.27 4.74 1.68 2.82 4.63 1.89 2.45 4.56 2.02 2.26 4.41 2.26 1.95 3.83 2.00 1.92
/ / /
0
5.41 1.07 5.06 5.27 1.21 4.34 5.10 1.36 3.74 4.92 1.55 3.18 5.04 1.74 2.89 5.02 2.03 2.48 5.13 2.16 2.37 4.40 2.10 2.09
/ / /
5
5.99 1.03 5.83 5.75 1.18 4.85 5.68 1.31 4.33 5.59 1.48 3.77 5.60 1.71 3.27 5.50 1.98 2.78 5.54 2.07 2.68 4.90 2.09 2.35 4.04 2.16 1.87
7
6.58 0.99 6.67 6.22 1.15 5.40 6.26 1.26 4.96 6.26 1.42 4.41 5.96 1.63 3.67 5.69 1.76 3.23 5.74 1.90 3.03 5.41 2.08 2.61 4.27 2.09 2.04
10
6.37 0.95 6.68 6.03 1.17 5.16 6.07 1.26 4.82 6.31 1.36 4.63 6.05 1.57 3.86 5.80 1.80 3.23 5.70 1.80 3.16 5.27 1.96 2.69 4.49 2.02 2.22
15 6.03 0.90 6.71 5.72 1.20 4.78 5.75 1.25 4.59 6.40 1.27 5.04 6.20 1.47 4.21 5.47 1.50 3.65 5.63 1.65 3.41 5.04 1.76 2.87 4.87 1.90 2.56
20 5.86 0.81 7.24 5.74 1.00 5.75 5.67 1.11 5.13 6.16 1.12 5.48 6.12 1.31 4.66 5.61 1.40 3.99 5.52 1.50 3.68 4.77 1.56 3.06 / / /
25 5.70 0.72 7.91 5.77 0.80 7.21 5.60 0.96 5.85 5.91 0.98 6.06 6.05 1.15 5.25 5.75 1.31 4.39 5.42 1.35 4.02 4.50 1.36 3.30 / / /
30 5.78 0.69 8.41 5.84 0.78 7.48 5.78 0.89 6.51 5.89 0.92 6.39 6.02 1.07 5.62 5.67 1.22 4.63 5.51 1.28 4.31 4.61 1.32 3.51 / / /
35 5.85 0.65 8.96 5.90 0.76 7.77 5.97 0.82 7.27 5.86 0.87 6.77 5.99 0.99 6.05 5.59 1.14 4.90 5.61 1.22 4.62 / / / / / /
40 6.30 0.58 10.8 6.38 0.67 9.51 6.36 0.74 8.57 6.33 0.80 7.88 6.38 0.93 6.86 6.00 1.15 5.20 / / / / / / / / /
43 6.57 0.54 12.2 6.67 0.62 10.8 6.59 0.69 9.50 6.62 0.77 8.63 6.61 0.89 7.39 6.25 1.16 5.38 / / / / / / / / /
Normal
DB
LWT
25 30 35 40 45 50 55 60 65
HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP
-25 1.90 1.07 1.78 1.65 1.08 1.52 1.56 1.19 1.31 1.42 1.20 1.19 1.28 1.18 1.09 / / / / / / / / / / / /
-20 2.82 1.15 2.45 2.57 1.38 1.86 2.20 1.49 1.48 1.98 1.57 1.26 1.83 1.61 1.14 1.73 1.61 1.07 1.50 1.52 0.99 / / / / / /
-15 3.26 1.03 3.17 3.07 1.06 2.88 2.90 1.17 2.48 2.66 1.31 2.02 2.22 1.40 1.59 1.96 1.46 1.34 1.69 1.41 1.20 1.61 1.56 1.03 / / /
-10
3.73 1.04 3.60 4.00 1.18 3.40 3.82 1.30 2.95 3.60 1.45 2.49 3.25 1.59 2.05 2.99 1.62 1.84 2.40 1.52 1.58 2.59 1.67 1.55
/ / /
-7
4.59 1.19 3.85 4.63 1.27 3.65 4.70 1.52 3.10 4.26 1.52 2.81 4.30 1.83 2.35 4.12 1.93 2.14 4.00 2.05 1.95 3.15 1.68 1.87
/ / /
-5
4.49 1.05 4.26 4.62 1.19 3.86 4.37 1.28 3.41 4.21 1.42 2.96 4.10 1.61 2.55 4.04 1.73 2.33 3.94 1.96 2.01 3.42 1.75 1.95
/ / /
0
4.99 0.96 5.19 4.80 1.08 4.46 4.60 1.20 3.85 4.53 1.40 3.23 4.46 1.49 3.00 4.41 1.75 2.52 4.43 1.78 2.49 3.87 1.86 2.09
/ / /
5
5.48 0.91 6.04 5.19 1.03 5.03 5.08 1.13 4.49 5.11 1.32 3.86 4.82 1.41 3.42 4.53 1.59 2.86 4.56 1.66 2.75 4.28 1.81 2.37 3.30 1.68 1.96
7
4.60 0.66 6.98 4.36 0.77 5.65 4.20 0.82 5.10 4.38 0.95 4.64 4.30 1.13 3.80 4.54 1.45 3.12 4.40 1.49 2.95 4.27 1.61 2.65 3.54 1.64 2.16
10
5.73 0.80 7.13 5.28 0.98 5.41 5.36 1.08 4.97 5.64 1.17 4.83 5.48 1.40 3.91 5.20 1.57 3.31 4.96 1.54 3.23 4.84 1.76 2.74 3.67 1.56 2.35
15 5.48 0.75 7.32 5.06 0.99 5.13 5.14 1.06 4.84 5.78 1.08 5.38 5.67 1.30 4.37 5.11 1.33 3.83 4.96 1.40 3.53 4.68 1.58 2.97 4.03 1.45 2.77
20 5.36 0.67 7.96 5.11 0.82 6.22 5.09 0.93 5.46 5.59 0.95 5.89 5.63 1.16 4.88 5.27 1.25 4.23 4.89 1.27 3.84 4.45 1.45 3.07 / / /
25 5.08 0.58 8.75 5.24 0.67 7.85 5.12 0.82 6.27 5.47 0.83 6.55 5.67 1.02 5.53 5.50 1.17 4.68 4.89 1.16 4.23 4.28 1.28 3.34 / / /
30 5.18 0.55 9.37 5.33 0.65 8.20 5.32 0.76 7.01 5.48 0.79 6.97 5.67 0.95 5.97 5.45 1.10 4.97 5.01 1.10 4.56 4.41 1.23 3.57 / / /
35 5.29 0.53 10.1 5.44 0.63 8.57 5.54 0.70 7.89 5.50 0.74 7.43 5.70 0.88 6.47 5.42 1.02 5.30 5.14 1.04 4.92 / / / / / /
40 5.78 0.47 12.2 5.77 0.55 10.6 5.73 0.61 9.37 5.78 0.66 8.70 5.89 0.80 7.38 5.66 1.00 5.67 / / / / / / / / /
43 6.08 0.44 13.9 6.09 0.50 12.1 6.00 0.57 10
.5 6.09 0.63 9.60 6.15 0.77 8.01 5.94 1.01 5.90 / / / / / / / / /
Minimum
DB
LWT
25 30 35 40 45 50 55 60 65
HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP HC PI COP
-25 1.23 0.68 1.80 1.12
0.72 1.55 1.18 0.89 1.33 1.09 0.90 1.20 0.86 0.79 1.10 / / / / / / / / / / / /
-20 1.73 0.69 2.50 1.53
0.80 1.90 1.42 0.94 1.51 1.39 1.08 1.29 1.23 1.07 1.15 1.28 1.18 1.08 1.14 1.14 1.00 / / / / / /
-15 1.68 0.52 3.25 1.65
0.56 2.95 1.55 0.61 2.54 1.64 0.79 2.07 1.60 1.00 1.61 1.52 1.12 1.36 1.25 1.00 1.25 1.23 1.17 1.05 / / /
-10 1.65 0.45 3.70 1.75
0.50 3.50 1.71 0.56 3.04 2.09 0.82 2.56 2.17 1.04 2.09 2.23 1.19 1.88 1.82 1.14 1.60 2.02 1.27 1.58 / / /
-7 1.16 0.29 4.01 1.18
0.31 3.76 1.25 0.37 3.34 2.06 0.70 2.93 2.08 0.86 2.42 2.05 0.94 2.18 1.88 0.98 1.91 2.22 1.16 1.91 / / /
-5 1.36 0.31 4.38 1.36
0.34 3.98 1.42 0.40 3.51 2.06 0.67 3.07 2.16 0.83 2.60 2.09 0.92 2.27 1.99 0.98 2.04 2.29 1.15 1.99 / / /
0 1.45 0.27 5.37 1.51
0.33 4.61 1.42 0.36 3.98 2.12 0.63 3.34 2.22 0.72 3.07 2.24 0.90 2.48 2.21 1.00 2.21 2.61 1.22 2.14 / / /
5 1.97 0.31 6.28 1.99
0.38 5.23 1.92 0.41 4.66 2.58 0.64 4.01 2.59 0.74 3.52 2.58 0.91 2.84 2.79 1.05 2.66 3.05 1.25 2.44 2.33 1.14 2.04
7 2.35 0.32 7.28 2.34
0.40 5.89 2.31 0.43 5.39 2.95 0.62 4.78 3.22 0.82 3.91 3.22 1.00 3.23 3.65 1.16 3.15 3.56 1.30 2.75 2.71 1.19 2.26
10 1.95 0.26 7.46 1.77
0.31 5.67 1.92 0.37 5.21 2.84 0.56 5.06 3.27 0.81 4.06 3.19 0.93 3.44 3.60 1.07 3.35 3.53 1.24 2.85 2.87 1.17 2.44
15 2.36 0.31 7.72 2.25
0.41 5.42 2.25 0.44 5.12 2.96 0.52 5.68 3.43 0.75 4.58 3.37 0.84 4.01 4.05 1.10 3.70 3.68 1.23 3.00 3.07 1.06 2.90
20 2.64 0.31 8.41 2.81
0.43 6.58 3.01 0.52 5.78 3.88 0.62 6.23 3.80 0.74 5.12 3.65 0.82 4.44 3.70 0.92 4.04 3.19 0.99 3.23 / / /
25 3.14 0.34 9.25 3.40
0.41 8.30 3.52 0.53 6.63 4.31 0.62 6.94 4.35 0.75 5.81 4.31 0.88 4.92 3.89 0.87 4.44 3.28 0.93 3.52 / / /
30 3.32 0.34 9.90 3.59
0.41 8.68 3.79 0.51 7.43 4.03 0.55 7.37 4.42 0.71 6.27 4.39 0.84 5.22 4.10 0.85 4.79 3.48 0.93 3.76 / / /
35 3.92 0.37 10.6 4.01
0.44 9.08 3.91 0.47 8.36 4.04 0.51 7.87 4.44 0.65 6.80 4.47 0.80 5.57 4.38 0.85 5.18 / / / / / /
40 4.28 0.33 12.9 4.27 0.38 11
.2 4.51 0.45 9.93 4.56 0.49 9.22 4.85 0.62 7.76 4.86 0.82 5.96 / / / / / / / / /
43 4.53 0.31 14.7 4.53 0.35 12.8 4.75 0.43 11.1 4.83 0.48 10
.2 5.15 0.61 8.42 5.19 0.84 6.20 / / / / / / / / /
Abbreviaons:
LWT: Leaving water temperature (°C )
DB: Dry-bulb temperature for Outdoor air temperature (°C )
HC: Total heang capacity (kW)
PI: Power input (kW)
