INVENTOR MGHP-12 User Manual

INSTALLATIONINSTRUCTIONS
Exhausthoseinstallation:
Theexhausthoseandadaptormustbeinstalledorremoved
inaccordancewiththeusagemode.
Theexhausthosecanbecompressedorextended
moderatelyaccordingtotheinstallationrequirement,
butitisdesirabletokeepthehoselengthtoaminimum.
1.InstalltheadaptorBandadaptorIontotheexhausthoseas
showninFig.16aorFig.16b.Refertothepreviouspagesfor
windowkitinstallation.
2.ResertthehookoftheExhausthoseintotheholeseatofthe
airoutletandslidedowntheExhausthosealongthearrow
direction(SeeFig.17)forinstallation.
IMPORTANT:
DONOTOVERBENDTHEEXHAUSTHOSE(SEEFig.19)
12
Fig.16a
Fig.17
Fig.19
(NotapplicabletotheunitswithoutadaptorA,expansion
plugsandwoodenscrewsofAccessories)
1.Prepareaholeinthewall.InstallthewallExhaustadaptorA
ontothewall(outside)byusing4expansionplugsand
woodenscrews,besuretofixthoroughly.(SeeFig.18)
2.AttachtheExhausthosetowallExhaustadaptorA.
Theexhausthosecanbeinstalledintothewall
.
Fig.18
max120CM
min30CM
AdaptorA
Expansionplug
position
Adaptor
cap
Note:
Covertheholeusingtheadaptorcapwhennotinuse.
Fig.16b
COOL,HEAT(heatpumptype)orAUTO
mode
FAN,DEHUMIDIIFYorHEAT(electricalheattype)
mode
Install
Remove
CAUTION:
Makesurethatthereisnoobstaclearoundtheairoutletof
theexhausthose(intherangeof500mm)inordertothe
exhaustsystemworksproperly.
Holeseat
Hook
