Installationinaslidingsashwindow
1.Cutthefoamseal(adhesivetype)totheproperlengthand
attachittothewindowframe.SeeFig.12.
2.Attachthewindowsliderkittothewindowstool.Adjustthe
lengthofthewindowsliderkitaccordingtothewidthof
window,shortentheadjustablewindowkitifthewidthof
windowislessthan26.5inches.
Openthewindowsashandplacethewindowsliderkiton
thewindowstool.SeeFig.13.
3.Cutthefoamseal(adhesivetype)totheproperlength
andattachitonthetopofthewindow.ShownasinFig.14.
4.Closetheslidingsashsecurelyagainstthewindow.
5.Cutthefoamsealtoanappropriatelengthandseathe
opengapbetweenthetopwindowsashandouterwindow
sash.ShownasinFig.15.
Foamseal
FoamsealA
(adhesivetype)
Fig.12
Fig.13
Fig.14
Fig.15
Window
panel
NOTE:Alltheillustrationsinthismanualareforexplanation
purposeonly.Yourunitmaybeslightlydifferent.The
actualshapeshallprevail.
26.5 ~48.0
