2 System overview
The Pulsar is an innovative extractor fan with a
contemporary design. It improves the basic ventilation in
your rooms and enables continuous ventilation to reduce
humidity and odours in wet rooms (WC/bathroom/shower
room/laundry room).
Additionally, the Pulsar can be used as an overow fan.
The Pulsar can be used in conjunction with the aV100 wall
mounting set or installed in another wall mounting sleeve
with a diameter of 100 ... 140 mm (non-return valve must
be retrotted on site in this case).
Installation is possible in ceilings and exterior walls. If the
Pulsar extractor fan is used as an overow fan, it can also
be installed in interior walls. The Pulsar allows connection
directly to the 230 V mains or connection via a power
supply unit. Please note that not all functions are available
when connecting to DC 12 V.
To ensure that the Pulsar does not interfere with other
ventilation units/devices and that its function is not inter-
fered with by other ventilation operations, it must always
be installed in its own wall sleeve. There must be no
obstacles or other objects in this sleeve that could interfere
with the airow. In order to avoid any condensation from
forming in wall sleeves (in winter), they must be insulated
at the points where they run through unheated areas, such
as cold attics.
Improper Use
Use contrary to the intended purpose leads to the exclusion
of any liability claims. Any use that is not mentioned in the
chapter intended use is considered improper use.
In particular, do not install/operate the device in areas whe-
re the following may occur:
• Environment containing strong oils or lubricants.
• Flammable, aggressive and corrosive gases, liquids or
vapours.
• Ambient temperatures outside the range of 5 – 50 °C
• Possible obstacles preventing access or the removal of
the fan.
Qualied personnel
Installation and electrical connection of the unit may only
be carried out by qualied personnel (see also icon ).
Qualied personnel in the sense of the safety instructions
in this documentation are persons who are authorised to
install, commission and label devices, systems and circuits
in accordance with the standards of safety technology.
Conformity
The Pulsar meets the requirements for mechanical safety
(DIN EN 60335-2-80).
The Pulsar is equipped with a Bluetooth radio system.
Bluetooth LE: -12dBm EIRP (63μW), nominal 2450 MHz.
inVENTer GmbH hereby declares that the Bluetooth radio
system installed in the device complies with Directive
2014/53/EU. The full text of the EU Declaration of
Conformity is available at the following internet address:
https://www.inventer.eu/downloads/
