P6.04 RT2 SELECTION 0~14 0~14 0
P6.05 RT3 SELECTION 0~14 0~14 0
P6.06 RT4 SELECTION 0~14 0~14 0
P6.07 RT5 SELECTION 0~14 0~14 0
P6.08 RT6 SELECTION 0~14 0~14 0
P6.09 RT7 SELECTION 0~14 0~14 0
P6.10 RT8 SELECTION 0~14 0~14 0
These parameters are to set the output function of relay on water-supply card,the
detailsis as follows:
Setting value Function Description
0 No function Terminal is invalid.
1 Connect A for var freq CON
2 Connect A for pow freq CON
3 Connect B for var freq CON
4 Connect B for pow freq CON
5 Connect C for var freq CON
6 Connect C for pow freq CON
7 Connect D for var freq CON
8 Connect D for pow freq CON
9 Connect E for var freq CON
10 Connect E for pow freq CON
11 Connect F for var freq CON
12 Connect F for pow freq CON
13 Connect G for var freq CON
14 Connect G for pow freq CON
Variable frequency pump needs two control signals: frequency control and grid
frequency control,but grid frequency
