INVT CHV160A Series - Typical Wiring Diagram

C.TY TNHH TỰ ĐỘNG HÓA VIỆT TRUNG 02413.281.181-
0989.984.666
Website:www.viet-trung.com.vn Đ/c:194-Nguyễn Trãi-Võ Cường-
TP.Bắc Ninh
DIEN DAN BIEN TAN HTTP://BIENTAN.HNSV.COM
CHV160A series special inverter for water supply
4 . 3 Ty pi ca l W i r i ng D i agram
DCL DC
External Braking Unit
3 phase
380V±15%
50 / 60Hz
Protect circuit
R
S
T
Reactor
P1 (+) (-)
(+)
BR1
(-)
BR2
+
Braking
Resister
U
V
M
W
Main circuit
PE
