5.3.2 Stand-by
At stop or running status, parameters of multi-status can be displayed. W hether or not to
display this parameter can be chosen through Function Code P7.06 (Running status
display selection) and P7.07 (Stop status display selection) according to binary bits, the
detailed description of each bit please refer to the function code description of P7.06 and
P7.07.
In stop status, there are sixteen parameters which can be chosen to display or not. They
are: reference frequency, DC bus voltage, PID setting, PID feedback, input terminal
status, output terminal status, analog AI1, analog AI2, and some reserved parameters.
Whether or not to display can be determined by setting the corresponding binary bit of
P7.07. Press the 》 /SHIFT to scroll through the parameters in right order.
5.3.3 Operation
In running status, there are twenty one running parameters which can be chosen to
display or not. They are: running frequency, reference frequency, DC bus voltage, output
voltage, output current, rotating speed, output power, PID setting, PID feedback, input
terminal status, output terminal status, analog AI1, analog AI2 and some reserved
parameters. W hether or not to display can be determined by setting the corresponding
binary bit of P7.06. Press the 》 /SHIFT to scroll through the parameters in right order .
5.3.4 Fault
In fault status, inverter will display parameters of STOP status besides parameters of fault
status. Press the 》 /SHIFT to scroll through the parameters in right order.
30
DIEN DAN BIEN TAN HTTP://BIENTAN.HNSV.COM
CHV160A series special inverter for water supply
6. DETAILED FUNCTION DESCRIPTION
