Power
Size
Figure A.2 Dimensions (22kW ～ 132kW )
A(mm) B(mm) H(mm) W(mm) D(mm) Installation
(kW)
Installation Dimension External Dimension
Hole(mm)
5.5~7.5 C 147.5 237.5 250 160 175 5
11 ～ 18.5 D 206 305.5 320 220 180 6
22 ～ 37 E 176 454.5 467 290 215 6.5
45 ～ 75 F 230.0 564.5 577.0 375.0 270.0 7.0
90 ～ 132 G 320.0 738.5 755.0 460.0 330.0 9.0
111
