For
the
convenience
of
setting
function
code
by
using
operation
panel,
the
function
group
number
is
corresponding
to
Stage
1
menu,
the
function
code
is
corresponding
to
Stage
2
menu
and
the
function
code
parameter
is
corresponding
to
Stage
3
menu.
1.
The
column
of
function
table
is
described
as
follows:
The
1
st
column
“Function
Code”
is
the
function
parameter
group
and
parameter
code.
The
2
nd
column
“Name”
is
the
complete
name
of
the
function
parameter.
The
4
th
column
“Setting
Range”
is
the
effective
setting
value
range
of
the
function
parameter,
shown
on
the
operation
panel
LCD
(liquid
crystal
display).
The
5
th
“Default”
is
the
original
factory
setting
value
of
this
function
parameter.
The
6
th
“Modify”
is
the
modification
performance
of
the
function
parameter
(i.e.
whether
or
not
it
is
permitted
to
modify
and
the
modification
conditions),
explained
as
follows,
“
○
”:
indicates
that
the
setting
value
of
this
parameter
can
be
modified
when
the
inverter
is
either
in
stop
or
operating
status;
“
◎
”:
means
that
the
setting
value
of
this
parameter
cannot
be
modified
when
the
inverter
is
in
operating
status;
(Inverter
has
done
the
automatic
detection
restriction
to
the
modification
performance
of
each
parameter,
helping
user
to
prevent
mis-modification.)
The
7
th
column
“LCD
Display”
is
the
brief
description
of
function
parameter
name
on
the
operation
panel
LCD
(liquid
crystal
display);
2.
“Parameter
Digital
System”
is
the
decimal
system.
If
parameters
are
expressed
in
hexadecimal
system,
the
value
at
each
digit
is
independent
when
the
parameter
is
edited,
and
the
numeric
area
of
some
digits
can
be
hexadecimal
(0-F).
3.
“LCD
Display
Description”
is
only
valid
when
using
external
LCD
operation
