P1.09
FREQ
STOP BRAK DELAY
STOP BRAK CURR
STOP BRAK
TIME
0.00~P0.07 0.00~10.00 0.00Hz
0.0~50.0s 0.0~50.0 0.0s
0.0~150.0% 0.0~150.0 0.0%
0.0~50.0s 0.0~50.0 0.0s
Starting frequency of DC braking: Start the DC braking when running frequency reaches
starting frequency determined by P1.06.
Waiting time before DC braking: Inverter blocks the output before starting the DC braking.
After this waiting time, the DC braking will be started. It is used to prevent over-current
fault caused by DC braking at high speed.
DC braking current: The value of P1.08 is the percentage of rated current of inverter. The
bigger the DC braking current, the greater the braking torque.
DC braking time: The time used to perform DC braking. If the time is 0, the DC braking
will be invalid.
