1:AI1
2:AI2
PID given is set by the analog, and the setting is similar with analog input of P0.02.But the
unit is decided by P3.00.
43
DIEN DAN BIEN TAN HTTP://BIENTAN.HNSV.COM
CHV160A series special inverter for water supply
3: Modbus
The reference frequency is set through RS485. For details, please refer to operation
manual of communication card.
4: Time water supply
The function parameter is determined by P9.01~P9.17.
5: Multi-press set
PID given is confirmed by the combination of - terminals status (P5 group) and
P9.18~P9.33.
When the frequency source is set to be PID or P8.00 = 1(water-supply function is valid),
the function will be valid. W hen the - target value of - PID is a relative percentage, -100%
is corresponding to P3.02 (maximum value of PID).
Function
Code
Name Description
0: AI1 feed
1: AI2 feed
Setting
Range
