INVT GD10-0R4G-S2-B User Manual

Goodrive10 Series Mini VFD Function parameters
-28-
Function
code
Name
Description
Default
Modify
current running frequency.
The multi-step speed has the priority when
P00.06 or P00.07 does not equal to 6, but the
setting step can only be the 1–15 steps. The
setting step is 1–15 if P00.06 or P00.07 equals
to 6.
7: PID control setting
The running mode of the VFD is process PID
control when P00.06=7 or P00.07=7. It is
necessary to set P09. The running frequency of
the VFD is the value after PID effect. See P09
for the detailed information of the preset source,
preset value, feedback source of PID.
8: Modbus communication setting
The frequency is set by Modbus communication.
See P14 for detailed information.
P00.08
B
frequency
command
reference
0: Max.output frequency, 100% of B frequency
setting corresponds to max. output frequency
1: A frequency command, 100% of B frequency
setting corresponds to the max. output
frequency. Select this setting if it needs to adjust
on the base of A frequency command
1
○
P00.09
Combinatio
n of the
setting
source
0: A, the current frequency setting is A freauency
command
1: B, the current frequency setting is B
frequency command
2: A+B, the current frequency setting is A
frequency command + B frequency command
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max (A, B): The bigger one between A
frequency command and B frequency is the set
frequency.
5: Min (A, B): The lower one between A
frequency command and B frequency is the set
frequency.
Note: The combination manner can be shifted
by P05 (terminal function).
0
○
