Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure
15
LED off means that the VFD is in the
stopping state; LED blinking means the
VFD is in the parameter autotune state;
LED on means the VFD is in the running
state.
FED/REV LED
LED off means the VFD is in the forward
rotation state; LED on means the VFD is
in the reverse rotation state.
LED for keypad operation, terminals
operation and remote communication
control
LED off means that the VFD is in the
keypad operation state; LED blinking
means the VFD is in the terminals
operation state; LED on means the VFD
is in the remote communication control
state.
LED for faults
LED on when the VFD is in the fault state;
LED off in normal state; LED blinking
means the VFD is in the pre-alarm state.
Mean the unit displayed currently
5-figure LED display displays various monitoring data and alarm code such
as set frequency and output frequency.
