INVT GD100-2R2G-SS2-PV User Manual

Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure
16
Serial
No.
Name
Description
Display
Mean
Display
Mean
Display
Mean
Display
Mean
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
H
I
L
N
n
o
P
r
S
t
U
v
.
-
4
Buttons
PRG
ESC
Programming
key
Enter or escape from the first level menu
and remove the parameter quickly.
DATA
ENT
Entry key
Enter the menu step-by-step.
Confirm parameters.
UP key
Increase data or function code
progressively.
DOWN key
Decrease data or function code
progressively
SHIFT
Right-shift key
Move right to select the displaying
parameter circularly in stopping and
running mode.
Select the parameter modifying digit
during the parameter modification.
RUN
Run key
This key is used to operate on the VFD in
key operation mode.
STOP
RST
Stop/
Reset key
This key is used to stop in running state
and it is limited by function code P07.04.
This key is used to reset all control
modes in the fault alarm state.
QUICK
JOG
Quick key
The function of this key is confirmed by
function code P07.02.
5
Keypad
port
External keypad port. When keypads are valid, both the local and external
keypad LEDs are on.
