Goodrive200 inverters Basic operation instruction
151
Function
code
Name Detailed instruction of parameters
Default
value
P02.04 Rated voltage of AM 1
0~1200V
Depend
on model
P02.05 Rated current of AM 1
0.8~6000.0A
Depend
on model
P02.06 Stator resistor of AM 1
0.001~65.535Ω
Depend
on model
P02.07 Rotor resistor of AM 1
0.001~65.535Ω
Depend
on model
P02.08
Leakage inductance of
AM 1
0.1~6553.5mH
Depend
on model
P02.09 Mutual inductance of AM 1
0.1~6553.5mH
Depend
on model
P02.10 Non-load current of A
M 1
0.1~6553.5A
Depend
on model
7.7 Start-up and stop control
The start-up and stop control of the inverter includes three states: start after the running command
during normal powering on, start after the restarting function becomes valid during normal
powering on and start after the automatic fault reset. Below is the detailed instruction for three
starting.
There are three starting modes for the inverter: start from the starting frequency directly, start after
the DC braking and start after the rotation speed tracking. The user can select according to
different situations to meet their needs.
For the load with big inertia, especially in the cases where the reverse rotation may occur, it is
better to select starting after DC braking and then starting after rotation speed tracking.
1. The starting logic figure of starting after the running command during the normal powering on
