INVT GD300-037G-4 User Manual

Goodrive300 Series VFD Basic operation instruction
131
Function
code
Name
Detailed instruction of parameters
Default
value
P03.07
Compensation coefficient
of electromotion slip in
vector control
50%–200%
100%
P03.08
Compensation coefficient
of braking slip in vector
control
50%–200%
100%
P03.09
Current loop proportional
coefficient P
0–65535
1000
P03.10
Current loop integral
coefficient I
0–65535
1000
P03.11
Torque setting method
This parameter is used to enable the
torque control mode, and set the torque.
0: Torque control is invalid
1: Keypad setting torque (P03.12)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8: PROFIBUS/CANopen communication
setting torque
9: Ethernet communication setting torque
10: Reserved
Note: For setting modes of 2–10, 100%
corresponds to three times of the rated
current of the motor.
0
P03.12
Keypad setting torque
-300.0%–300.0%
(rated current of the motor)
50.0%
P03.13
Torque reference filter
time
0.000–10.000s
0.010s
P03.14
Upper frequency of
forward rotation in torque
control
0: Keypad (P03.16 sets P03.14, P03.17
sets P03.15)
1: AI1
2: AI2
3: AI3
0
P03.15
Upper frequency of
reverse rotation in torque
control
0
