INVT GD300-037G-4 User Manual

Goodrive300 Series VFD Fault tracking
193
Code
Fault
Cause
Solution
fault
The keypad wire is too long
and affected by strong
interference.
There is mistake on the data
storage of the keypad.
Change the hardware and ask for
service.
Repack-up the data in the keypad.
E-DP
PROFIBUS
communication
fault
Communication address is not
correct.
Corresponding resistor is not
dialed
The files of main stop GSD
does not set sound
The peripheral interference is
too large.
Check related setting
Check the surrounding
environment, and eliminate
interference effects.
E-NET
Ethernet
communication
fault
The Ethernet address is not
set right.
The Ethernet communication
is not selected to right.
The peripheral interference is
too large.
Check the related setting.
Check the communication method
selection.
Check the surrounding
environment, and eliminate
interference effects.
E-CAN
CANopen
communication
fault
The connection is not sound
Corresponding resistor is not
dialed
The communication baud rate
is not matched
The peripheral interference is
too large.
Check the connection
Draw out the correspond resistor
Set the same baud rate
Check the surrounding
environment, and eliminate
interference effects.
ETH1
Grounding
shortcut fault 1
The output of the VFD is short
circuited with the ground.
There is fault in the current
detection circuit.
The actual motor power
sharply differs from the VFD
power.
Check if the connection of the
motor is normal or not
Change the hall
Change the main control panel
Set motor parameters correctly.
ETH2
Grounding
shortcut fault 2
The output of the VFD is short
circuited with the ground.
There is fault in the current
detection circuit.
The actual motor power
sharply differs from the VFD
Check if the connection of the
motor is normal or not
Change the Hall
Change the main control panel
Set motor parameters correctly.
