INVT GD300-075G-4 - Page 224

Goodrive300 Series VFD Communication protocol
219
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
2009H
Special control command word
Bit0–1:=00: motor 1 =01: motor 2
=10: motor 3 =11: motor 4
Bit2:=1 torque control prohibit
=0: torque control prohibit invalid
Bit3:=1 power consumption clear
=0:no power consumption clear
Bit4:=1 pre-exciting enabling
=0: pre-exciting disabling
Bit5:=1 DC braking enabling
=0: DC braking disabling
R/W
200AH
Virtual input terminal command , range:
0x000–0x1FF
R/W
200BH
Virtual output terminal command , range:
0x00–0x0F
R/W
200CH
Voltage setting value (special for V/F
separation)
(0–1000, 1000 corresponds to the 100.0%)
R/W
200DH
AO output setting 1
(-1000–1000, 1000 corresponds to 100.0%)
R/W
200EH
AO output setting 2
(-1000–1000, 1000 corresponds to 100.0%)
R/W
SW 1 of the VFD
2100H
0001H:forward running
R
0002H:forward running
0003H:stop
0004H:fault
0005H: POFF state
0006H: pre-exciting state
SW 2 of the VFD
2101H
Bit0: =0: not ready for operation =1: ready for
operation
Bi1–2:=00:motor 1 =01:motor 2
=10:motor 3 =11:motor 4
Bit3: =0:asynchronous motor
=1:synchronous motor
Bit4: =0:pre-alarm without overload
=1:overload pre-alarm
Bit5– Bit6: =00: keypad control
R
