INVT GD300-075G-4 - Page 225

Goodrive300 Series VFD Communication protocol
220
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
=01: terminal contorl
=10: communication control
Fault code of the
VFD
2102H
See the fault type instruction
R
Identifying code
of the VFD
2103H
GD300-----0x010a
R
Operation
frequency
3000H
0–Fmax(unit: 0.01Hz)
R
Setting freqency
3001H
0–Fmax(unit: 0.01Hz)
R
Bus voltage
3002H
0.0–2000.0V (unit: 0.1V)
R
Output voltage
3003H
0–1200V (unit: 1V)
R
Output current
3004H
0.0–3000.0A (unit: 0.1A)
R
Rotation speed
3005H
0–65535 (unit: 1RPM)
R
Output power
3006H
-300.0–300.0% (unit: 0.1%)
R
Output torque
3007H
-250.0–250.0% (unit: 0.1%)
R
Close loop
setting
3008H
-100.0–100.0% (unit: 0.1%)
R
Close loop
feedback
3009H
-100.0–100.0% (unit: 0.1%)
R
Input IO state
300AH
000–1FF
R
Output IO state
300BH
000–1FF
R
Analog input 1
300CH
0.00–10.00V (unit: 0.01V)
R
Analog input 2
300DH
0.00–10.00V (unit: 0.01V)
R
Analog input 3
300EH
0.00–10.00V (unit: 0.01V)
R
Analog input 4
300FH
R
Read input of
high-speed pulse
1
3010H
0.00–50.00kHz (unit: 0.01Hz)
R
Read input of
high-speed pulse
2
3011H
R
Read the current
stage of
multi-step speed
3012H
0–15
R
External length
3013H
0–65535
R
External
counting
3014H
0–65535
R
