INVT GD350-011G-4 User Manual

Goodrive350 series high-performance multi-function inverter Chapter 3
-13-
3.6 Rated value
3.6.1 AC 3PH 380V(-15%)–440V(+10%) rated value
Product model
Output power
(kW)
Input current
(A)
Output
current (A)
Carrier
frequency (kHz)
GD350-1R5G-4
1.5
5.0
3.7
1–15(8)
GD350-2R2G-4
2.2
5.8
5
1–15(8)
GD350-004G-4
4
13.5
9.5
1–15(8)
GD350-5R5G-4
5.5
19.5
14
1–15(8)
GD350-7R5G-4
7.5
25
18.5
1–15(8)
GD350-011G-4
11
32
25
1–15(8)
GD350-015G-4
15
40
32
1–15(4)
GD350-018G-4
18.5
47
38
1–15(4)
GD350-022G-4
22
51
45
1–15(4)
GD350-030G-4
30
70
60
1–15(4)
GD350-037G-4
37
80
75
1–15(4)
GD350-045G-4
45
98
92
1–15(4)
GD350-055G-4
55
128
115
1–15(4)
GD350-075G-4
75
139
150
1–15(2)
GD350-090G-4
90
168
180
1–15(2)
GD350-110G-4
110
201
215
1–15(2)
GD350-132G-4
132
265
260
1–15(2)
GD350-160G-4
160
310
305
1–15(2)
GD350-185G-4
185
345
340
1–15(2)
GD350-200G-4
200
385
380
1–15(2)
GD350-220G-4
220
430
425
1–15(2)
GD350-250G-4
250
460
480
1–15(2)
GD350-280G-4
280
500
530
1–15(2)
GD350-315G-4
315
580
600
1–15(2)
GD350-350G-4
350
625
650
1–15(2)
GD350-400G-4
400
715
720
1–15(2)
GD350-500G-4
500
890
860
1–15(2)
Note:
1. The input current of 1.5–500kW inverter is measured in cases where the input voltage is 380V
without additional reactors;
2. The rated output current is the output current when the output voltage is 380V;
3. Within allowable input voltage range, the output current/power cannot exceed rated output
current/power.
