INVT Goodrive 300-16

Goodrive300-16 special inverter for HVAC Appendix A
125
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
corresponds to 100.0%)
2012H
PID2 feedback, range (0~1000, 1000
corresponds to 100.0%)
W/R
2013H
Water level of inlet sump, range (0~1000,
1000 corresponds to 100.0%)
W/R
SW 2 of the
inverter
2101H
Bit7: fire enabled state
Bit8: low PID1 feedback pre-alarm
Bit9: high PID1 feedback pre-alarm
Bit10: PID1 hibernation state
Bit11: realtime clock fault
Bit12: PID2 running state
Bit13: water shortage of inlet sump
Bit14: pre-alarm output
R
Close loop PID1
reference
3008H
R
Close loop PID1
feedback
3009H
R
Close loop PID2
reference
3017H
R
Close loop PID2
feedback
3018H
R
2. Profibus-DP/CANopen/Devicenet communication
Control word (CW)
Bit:0~7
Communication
control
command
9
Emergency deceleration to stop
Bit15
Fire signal
triggering
1
Enabled
0
Disabled
3. BACnet communication
Control word (CW)
Bit5
Emergency
deceleration to
stop
9
Enabled
1
Disabled
Bit15
Fire signal
triggering
1
Enabled
0
Disabled
