Goodrive300-16 special inverter for HVAC Commissioning guidelines
13
Type
Code
Terminal name
Description
PW
External power
supply
Provide the input switch working
power supply from external to
internal.
Voltage range: 12~24V
Analog input
and output
AI1
Analog input 1
1. Input range: AI1/AI2 voltage and
current can be chosen
0~10V/0~20mA;
AI3:-10V~+10V
2. Input impedance: voltage input:
20kΩ; current input: 500Ω
3. The voltage or current input is
set by the jumper
4. Resolution: the minimum one is
5mV when 10V corresponds to
50Hz
AI2
Analog input 2
AI3
Analog input 3
AO1
Analog output 1
1. Output range: 0~10V or 0~20mA
2. The voltage or the current output
is set by the jumper
3. Resolution 10bit
AO2
Analog output 2
Switch input
and output
S1
Switch input 1
1. Internal impedance: 3.3kΩ
2. 12~30V voltage input is available
3. The terminal is the dual-direction
input terminal
4. Max. input frequency: 1kHz
S2
Switch input 2
S3
Switch input 3
S4
Switch input 4
S5
Switch input 5
S6
Switch input 6
S7
Switch input 7
S8
Switch input 8
HDI
Switch input
Except for S1~S8, this terminal can
be used as high frequency input
channel.
Max. input frequency: 50kHz
HDO
Switch output
1. Switch capacity: 50mA/30V
