INVT Goodrive 300-16

Goodrive300-16 special inverter for HVAC Commissioning guidelines
16
3.3.3 List of control parameters
List of relevant function parameters (take 3 power frequency motors for example)
Function
code
Name
Set
value
Remark
P00.00
Speed control mode
2
V/F control
P00.01
Run command
channel
1
Terminal control, adjustable according to
the actual situations
P00.03
Max. output
frequency
50.00Hz
Adjustable according to the actual
situations
P00.04
Upper limit of
running frequency
50.00Hz
Adjustable according to the actual
situations
P00.05
Lower limit of
running frequency
20.00Hz
Adjustable according to the actual
situations
P00.11
ACC time 1
4.0s
Adjustable according to the actual
situations
P00.12
DEC time 1
4.0s
Adjustable according to the actual
situations
P05.01
S1 terminals function
1
Forward running
P05.02
S2 terminals function
7
Fault reset
P06.03
Relay RO1 output
01
In running
P06.04
Relay RO2 output
05
Fault output signal
P06.05
Relay RO3 output
35
Connect motor A power frequency
P06.06
Relay RO4 output
37
Connect motor B power frequency
P06.07
Relay RO5 output
39
Connect motor C power frequency
P09.02
Max. PID1 reference
1.000
Adjustable according to the actual
situations
P09.03
Upper limit of PID1
reference
1.000
Adjustable according to the actual
situations
P09.04
Lower limit of PID1
reference
0.100
Adjustable according to the actual
situations
P09.05
PID1 reference
source 1
2
Adjustable according to the actual
situations
P09.09
ACC/DEC time of
0.000
Adjustable according to the actual
