Goodrive35 Series Closed-loop Vector Control VFD Product overview
10
Function
Specification
Spindle stopping
For spindle positioning and control sequence
Internal 7 scale marks and 4 zero marks
Position reference
External zero-position detection switch positioning
Encoder Z phase positioning
Servo control
Pulse train reference: position control
Frequency division
output
Encoder frequency division output
(H1 and H2 VFDs)
Speed/position mode
Terminal shifting
Encoder
C1 support 100 kHz, D1 support 500 kHz, H1 support
300 kHz and H2 support 400 kHz
Positioning
Pulse Z and photoelectric switch positioning. Positioning
is accurate without overmodulation.
Others
Mountable method
Wall, flange and floor mountable
Temperature of the
running environment
-10–50°C , if temperature is above 40°C , derate 1% for
every additional 1°C .
Average non-fault time
2 years (25°C ambient temperature)
Protective degree
IP20
Pollution level
Level 2
Cooling
Air-cooling
Brake unit
Built-in for VFDs of 380 V (≤30 kW)
External for others
EMC filter
All products of the 380V series meet the IEC61800-3 C3
requirements.
External filters that meet the IEC61800-3 C2
requirements are optional.
3.4 Product nameplate
Figure 3-4 Product nameplate
Note: This is an example of the nameplate of standard Goodrive350 products. The CE/TUV/IP20
marking on the top right will be marked according to actual certification conditions.
Model: GD35-011G-4-H1
Power(Output): 11kW
Input: AC 3PH 380V(-15%)-440V(+10%) 32A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 25A 0Hz-400Hz
Shenzhen INVT electric Co., Ltd.
S/N: Made in China
IP20
