INVT Goodrive170-PV Series

Goodrive170-PV Series Solar Pump Inverter Installation guidelines
-8-
Environment
Condition
inverter. Otherwise, the inverter may be damaged.
Humidity

The relative humidity (RH) of the air is less than 90%.

Condensation is not allowed.
Storage
temperature
-40°C–70°C, with the air temperature change rate less than 1°C/minute.
Running
environment
Install the inverter in a place:
 Away from electromagnetic radiation sources.
 Away from oil mist, corrosive gases and combustible gases.
 Without the chance for foreign objects such as metal powder, dust,
oil and water to fall into the inverter (do not install the inverter onto
combustible objects such as wood).
 Without radioactive substances and combustible objects.
 Without hazard gases and liquids.
 With low salt content.
 Without direct sunlight.
Pollution
degree
Degree 2
Altitude
 Lower than 1000m;
 When the altitude exceeds 1000m, derate 1% for every increase of
1˚C.
 When the altitude exceeds 3000m, consult the local INVT dealer or
office.
Vibration
Max. vibration acceleration: 5.8m/s
2
(0.6g).
Installation
direction
Install the inverter vertically to ensure good heat dissipation
performance.
Note:
 The inverter must be installed in a clean and well-ventilated environment based on
the IP level.
 The cooling air must be clean enough and free from corrosive gases and conductive
dust.
3.1.2 Installation direction
The inverter can be installed on the wall or in a cabinet.
The inverter must be installed vertically. Check the installation position according to
following requirements. See Appendix D “Dimension drawings”.
