INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-33-
Function
code
Name
Parameter description
Default
value
Modify
different within differing power ranges, and
the default value will be configured as below
after autotuning and setting power range via
the touch screen.
P03.09 value
(reference)
P03.10 value
(reference)
Motor power
2000
1000
7.5–22kW
2500
1500
30–37kW
3000
1500
45–90kW
3500
2000
110–132kW
4000
2000
160–200 kW
model
P03.10
ACR integral
coefficient I
Depend
on
model
○
P03.20
Keypad setting of the
upper limit of
electromotive torque
0.0–300.0% (rated motor current)
180.0%
○
P03.21
Keypad setting of the
upper limit of brake
torque
0.0–300.0% (rated motor current)
180.0%
○
P03.22
Flux-weakening
coefficient in constant
power area
0.1–2.0
0.3
○
P03.23
Min. flux-weakening
point in constant power
area
10%–100%
20%
○
P03.24
Max. voltage limit
0.0–120.0%
100.0%
○
P03.25
Pre-excitation time
0.000–10.000s
0.300s
○
P03.26
Flux-weakening
proportional gain
0–8000
300
○
P03.27
Vector control speed
display selection
0: Display as per actual value
1: Display as per the set value
0
○
P04.00
V/F curve setting of
motor 1
0: Straight V/F curve
1: Multi-point V/F curve
2: Torque step-down V/F curve (1.3 order)
3: Torque step-down V/F curve (1.7 order)
4: Torque step-down V/F curve (2.0 order)
5: Reserved
0
◎
P04.01
Torque elevation of
motor 1
0.0%: (automatic)0.1%–10.0%
0.0%
○
P04.02
Torque elevation
cut-off of motor 1
0.0%–50.0% (relative to rated frequency of
motor 1)
20.0%
○
