INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-34-
Function
code
Name
Parameter description
Default
value
Modify
P04.03
V/F frequency point 1
of motor 1
0.00Hz–P04.05
0.00Hz
○
P04.04
V/F voltage point 1 of
motor 1
0.0%–110.0% (rated voltage of motor 1)
00.0%
○
P04.05
V/F frequency point 2
of motor 1
P04.03– P04.07
00.00Hz
○
P04.06
V/F voltage point 2 of
motor 1
0.0%–110.0% (rated voltage of motor 1)
00.0%
○
P04.07
V/F frequency point 3
of motor 1
P04.05–P02.02 (rated frequency of motor 1)
/P04.05–P02.16 (rated frequency of motor 1)
00.00Hz
○
P04.08
V/F voltage point 3 of
motor 1
0.0%–110.0% (rated voltage of motor 1)
00.0%
○
P04.09
V/F slip compensation
gain of motor 1
0.0–200.0%
100.0%
○
P04.10
Low-frequency
vibration control factor
of motor 1
0–100
10
○
P04.11
High-frequency
vibration control factor
of motor 1
0–100
10
○
P04.12
Vibration control
threshold of motor 1
0.00Hz–P00.03 (max. frequency)
30.00Hz
○
P04.26
Energy conservation
running selection
0: No action
1: Automatic energy-saving running
0
◎
P04.33
Flux-weakening
coefficient in constant
power area
1.00–1.30
1.00
○
P05.00
Reserved
Reserved
0
◎
P05.01
S1 terminal function
selection
0: No function
1: Forward running
2: Reverse running
3: Three-line running control
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10–24: Reserved
0
◎
P05.02
S2 terminal function
selection
0
◎
P05.03
S3 terminal function
selection
0
◎
P05.04
S4 terminal function
selection
0
◎
P05.05
S5 terminal function
selection
0
◎
P05.06
Reserved
◎
