INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-35-
Function
code
Name
Parameter description
Default
value
Modify
25: PID control pause
26–39: Reserved
40: Zero out power consumption
41: Maintain power consumption
42: Air filter blockage signal
43: Oil filter blockage signal
44: Separator blockage signal
45: Precision splitter blockage signal
46: External fault 1 (motor overtemperature)
47: External fault 2
48: Fan running control signal
49: Solenoid valve control signal
50: Cooling fan control signal of main motor
51–63: Reserved
P05.10
Input terminal polarity
selection
This function code is used to set the input
terminal polarity.
When the bit is set to 0, input terminal polarity
is positive;
When the bit is set to 1, input terminal polarity
is negative.
BIT8
BIT7
BIT6
BIT5
Reserved
BIT4
BIT3
BIT2
BIT1
BIT0
S5
S4
S3
S2
S1
Setting range: 0x000–0x1FF
0x000
○
P05.11
Digital filter time
0.000–1.000s
0.200s
○
P05.14
S1 terminal switch-on
delay
0.000–50.000s
0.000s
○
P05.15
S1 terminal switch-off
delay
0.000–50.000s
0.000s
○
P05.16
S2 terminal switch-on
delay
0.000–50.000s
0.000s
○
P05.17
S2 terminal switch-off
delay
0.000–50.000s
0.000s
○
P05.18
S3 terminal switch-on
delay
0.000–50.000s
0.000s
○
P05.19
S3 terminal switch-off
delay
0.000–50.000s
0.000s
○
P05.20
S4 terminal switch-on
0.000–50.000s
0.000s
○
