INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-36-
Function
code
Name
Parameter description
Default
value
Modify
delay
P05.21
S4 terminal switch-off
delay
0.000–50.000s
0.000s
○
P05.22
S5 terminal switch-on
delay
0.000–50.000s
0.000s
○
P05.23
S5 terminal switch-off
delay
0.000–50.000s
0.000s
○
P05.32
Lower limit value of P1
0.00V–P05.34
2.00V
○
P05.33
Corresponding setting
of lower limit of P1
-100.0%–100.0%
0.0%
○
P05.34
Upper limit value of P1
P05.32–10.00V
10.00V
○
P05.35
Corresponding setting
of upper limit of P1
-100.0%–100.0%
100.0%
○
P05.36
P1 input filter time
0.000s–10.000s
0.200s
○
P05.37
PT1 lower limit value
0.00V–P05.39
0.00V
○
P05.38
Corresponding setting
of lower limit of PT1
-100.0%–100.0%
-12.5%
○
P05.39
PT1 upper limit value
P05.37–10.00V
10.00V
○
P05.40
Corresponding setting
of upper limit of PT1
-100.0%–100.0%
93.8%
○
P05.41
PT1 input filter time
0.000s–10.000s
0.300s
○
P05.42
P2 lower limit value
0.00V–P05.44
2.00V
○
P05.43
Corresponding setting
of lower limit of P2
-100.0%–100.0%
0.0%
○
P05.44
P2 upper limit value
P05.42–10.00V
10.00V
○
P05.45
Corresponding setting
of upper limit of P2
-100.0%–100.0%
100.0%
○
P05.46
P2 input filter time
0.000s–10.000s
0.200s
○
P05.47
PT2 lower limit value
0.00V–P05.49
0.00V
○
P05.48
Corresponding setting
of lower limit of PT2
-100.0%–100.0%
-12.5%
○
P05.49
PT2 upper limit value
P05.47–10.00V
10.00V
○
P05.50
Corresponding setting
of upper limit of PT2
-100.0%–100.0%
93.8%
○
P05.51
PT2 input filter time
0.000s–10.000s
0.300s
○
P06.01
Reserved
0: Invalid
1: In running
2: In forward running
3: In reverse running
0
○
P06.02
RO3 output selection
0
○
P06.03
RO1 output selection
0
○
P06.04
RO2 output selection
0
○
