INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-37-
Function
code
Name
Parameter description
Default
value
Modify
4: In jogging
5: VFD fault
6–11: Reserved
12: Ready to run
13: In pre-exciting
14–19: Reserved
20: External fault is valid
21–22: Reserved
23: Modbus communication virtual terminal
output
24–26: Reserved
27: Fan start/stop control
28: Solenoid valve control output
29: Cooling fan control of main motor
30: Reserved
P06.05
Output terminal
polarity selection
This function code is used to set the output
terminal polarity.
When the bit is set to 0, output terminal
polarity is positive;
When the bit is set to 1, output terminal
polarity is negative.
BIT3
BIT2
BIT1
BIT0
RO2
RO1
RO3
Reserved
Setting range: 0–0xF
0
○
P06.06
Reserved
P06.07
Reserved
P06.08
RO3 switch-on delay
0.000–50.000s
0.000s
○
P06.09
RO3 switch-off delay
0.000–50.000s
0.000s
○
P06.10
RO1 switch-on delay
0.000–50.000s
0.000s
○
P06.11
RO1 switch-off delay
0.000–50.000s
0.000s
○
P06.12
RO2 switch-on delay
0.000–50.000s
0.000s
○
P06.13
RO2 switch-off delay
0.000–50.000s
0.000s
○
P06.14
AO1 output selection
0: Running frequency
1: Set frequency
2: Ramps reference frequency
3: Running speed
4: Output current (relative to two times the
rated current of the VFD)
5: Output current (relative to two times the
24
○
