INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-38-
Function
code
Name
Parameter description
Default
value
Modify
current of the motor)
6: Output voltage
7: Output power
8: Reserved
9: Output torque
10–13: Reserved
14: Value 1 set through Modbus
communication
15: Value 2 set through Modbus
communication
16–21: Reserved
22: Torque current (relative to three times the
rated current of the motor)
23: Ramp frequency reference (with sign)
24: Temperature PID output
25–30: Reserved
P06.17
Lower limit of AO1
output
-100.0%–P06.19
0.0%
○
P06.18
Corresponding AO1
output of lower limit
0.00V–10.00V
0.00V
○
P06.19
Upper limit of AO1
output
P06.17–100.0%
100.0%
○
P06.20
Corresponding AO1
output of upper limit
0.00V–10.00V
10.00V
○
P06.21
AO1 output filter time
0.000s–10.000s
0.000s
○
P07.00
User password
0–65535
0
○
P07.01
Function parameter
copy
0: No operation
1: Uploading function parameters from the
machine to keypad
2: Downloading function parameters
(including the motor parameters) from the
keypad to machine
3: Downloading function parameters
(excluding motor parameters of the P02 and
P12 groups) from the keypad to machine
4: Downloading function parameters (only
motor parameters of the P02 and P12 groups)
from the keypad to machine
Note:
After the parameter is set to 1, 2, 3 or 4, and
0
◎
