INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-40-
Function
code
Name
Parameter description
Default
value
Modify
12: VFD overload (OL2)
13: Phase loss on input side (SPI)
14: Phase loss on output side (SPO)
15: Rectifier module overheat (OH1)
16: Inverter module overheat (OH2)
17: External fault (EF)
18: 485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor autotuning fault (tE)
21: EEPROM operation fault (EEP)
22: PID feedback offline fault (PIDE)
23: Reserved
24: Running time reached (END)
25: Electronic overload (OL3)
26: Panel communication error (PCE)
27: Parameter upload error (UPE)
28: Parameter download error (DNE)
29–31: Reserved
32: To-ground short circuit fault 1 (ETH1)
33: To-ground short circuit fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Maladjustment fault (STo)
36: Underload fault (LL)
37: Reserved
38: Phase sequence fault (PSF)
39: 3PH current imbalance of the fan (SPOF)
40: Fan overload (OLF)
41: Encoder offline fault (ENC1O)
42: Encoder reverse fault (ENC1D)
43: Encoder Z pulse offline fault (ENC1Z)
P08.15
Bus voltage
pre-protection function
0–3
2
○
P08.16
Low-voltage protection
threshold
0.0V–2000.0V
300.0V
○
P08.17
Overvoltage
pre-protection
threshold
0.0V–2000.0V
780.0V
○
P08.18
Automatic restart delay
0.0–6000.0s
60.0s
○
P08.19
Low-voltage frequency
limit running time
0.0–6000.0s
60.0s
○
