INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-41-
Function
code
Name
Parameter description
Default
value
Modify
P08.20
High-frequency current
loop proportional gain
0–20000
1000
○
P08.21
High-frequency current
loop integral time
0–20000
1000
○
P08.23
High-frequency current
loop switching
frequency
0.0–100.0% (max. output frequency P00.03)
100.0%
○
P08.24
Fan control enable
selection
0–1
0: Enable fan control
1: Disable fan control
Note: Applicable to 7.5–15kW single-VFD
integrated machine only, used to control the
start/stop of power-frequency fan.
0
○
P08.25
Keypad lock enable
0: Do not lock keypad
1: Allow to lock keypad
Lock: Press PRG key+DATA key
simultaneously
Unlock: Keep DATA key pressed down and
then click V key by three times.
0
○
P08.26
Maintenance timing
mode
0: No timing during sleep
1: Timing during sleep
0
○
P09.00
PID reference source
0: Keypad digits (P09.01)
1: Analog P1-
2: Reserved
3: Analog P2-
4: Reserved
5: Multi-step
6: Modbus communication
7–9: Reserved
10: Pressure setting of dedicated function of
air compressor
0
○
P09.01
Keypad pre-set PID
reference
-100.0%–100.0%
0.0%
○
P09.02
PID feedback source
0: Analog P1-
1: Reserved
2: Analog P2-
3: Reserved
4: Modbus communication
5–7: Reserved
8: Pressure feedback of dedicated function of
0
○
