INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-44-
Function
code
Name
Parameter description
Default
value
Modify
protection
1: Enable input phase loss software protection
Note: LED ones detects input phase loss by
phase sequence detection circuit
LED tens:
0: Disable output phase loss protection
1: Enable output phase loss protection
LED hundreds:
0: Disable input phase loss hardware
protection
1: Enable input phase loss hardware
protection
Note: LED hundreds detects input phase loss
by hardware detection circuit
LED thousands:
0: Disable phase sequence protection
1: Enable phase sequence protection
P11.01
Frequency drop at
transient power dip
0: Disable
1: Enable
0
○
P11.02
Frequency drop rate at
transient power dip
0.00Hz–P00.03/s (max. frequency)
10.00Hz/
s
○
P11.03
Overvoltage stall
protection
0: Disable
1: Enable
1
○
P11.04
Overvoltage stall
protection voltage
120–150% (standard bus voltage) (380V)
140%
○
P11.05
Current limit selection
0x00–0x11
Ones: Current-limit action selection
0: Current-limit action is invalid
1: Current-limit action is always valid
Tens: Hardware current-limit overload alarm
selection
0: Hardware current-limit overload alarm is
valid
1: Hardware current-limit overload alarm is
invalid
01
◎
P11.06
Automatic current-limit
level
50.0–200.0%
160.0%
◎
P11.07
Frequency drop rate at
current limit
0.00–50.00Hz/s
10.00Hz/
s
◎
P11.13
Fault output terminal
0x00–0x11
0x00
○
