INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-45-
Function
code
Name
Parameter description
Default
value
Modify
action during fault
LED ones:
0: Acts during undervoltage fault
1: Do not act during undervoltage fault
LED tens:
0: Acts during automatic reset period
1: Do not act during automatic reset period
P11.14
Speed deviation
detection value
0.0–50.0%
10.0%
○
P11.15
Speed deviation
detection time
0.0–10.0s (No speed deviation protection
during 0.0)
0.5s
○
P11.16
Automatic frequency
reduction during
voltage drop
0: Invalid
1: Valid
1
○
P13.00
Pull-in current
reduction coefficient
0.0–100.0%
50.0%
○
P13.01
Initial magnetic pole
detection mode
0: Do not detection
1: High frequency superposition (reserved)
2: Pulse superposition (reserved)
0
◎
P13.02
Pull-in current 1
0.0%–100.0% rated motor current
20.0%
○
P13.03
Pull-in current 2
0.0%–100.0% rated motor current
10.0%
○
P13.04
Switching frequency of
pull-in current
0.00Hz–P00.03 (max. frequency)
30.00Hz
○
P13.05
High-frequency
superposing frequency
(reserved)
200Hz–1000Hz
500Hz
◎
P13.06
High frequency
superposing voltage
0.0–300.0% rated motor voltage
40.0%
◎
P13.08
Control parameter 1
0–FFFF
0x120
○
P13.09
Control parameter 2
0–300.00
5.00
○
P13.11
Maladjustment
detection time
Adjust the responsiveness of the function
used to prevent maladjustment. Increase the
value of P13.11 if load inertia is too large,
however, the response speed will be impacted
if the value is increased.
Setting range: 0.0–10.0s
0.5s
○
P13.12
High-frequency
compensation
coefficient
When the motor runs at rated speed, this
parameter is valid. If motor vibration occurs,
adjust this parameter properly.
Setting range: 0.0–100.0%
50.0%
○
