INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-46-
Function
code
Name
Parameter description
Default
value
Modify
P14.00
Local communication
address
1–247, 0 is broadcast address
2
○
P14.01
Communication baud
rated setup
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
4
○
P14.02
Data bit check setup
0: No parity check (N, 8, 1) for RTU
1: Even parity (E, 8, 1) for RTU
2: Odd parity (O, 8, 1) for RTU
3: No parity check (N, 8, 2) for RTU
4: Even parity (E, 8, 2) for RTU
5: Odd parity (O, 8, 2) for RTU
1
○
P14.03
Communication
response delay
0–200ms
5ms
○
P14.04
Communication
timeout fault time
0.0 (invalid), 0.1–60.0s
0.0s
○
P14.05
Transmission error
processing
0: Alarm and coast to stop
1: Do not alarm and continue running
2: Do not alarm and stop as per stop mode
(under communication control mode only)
3: Do not alarm and stop as per stop mode
(under all control modes)
0
○
P14.06
Communication
processing action
selection
0x00–0x11
LED ones: write operation action
0: There is response for write operation
1: There is no response for write operation
LED tens: Communication encryption
processing
0: Communication encryption setting is invalid
1: Communication encryption setting is valid
0x00
○
P17.00
Setting frequency
0.00Hz–P00.03
0.00Hz
●
P17.01
Output frequency
0.00Hz–P00.03
0.00Hz
●
P17.02
Ramps reference
frequency
0.00Hz–P00.03
0.00Hz
●
P17.03
Output voltage
0–1200V
0V
●
P17.04
Output current
0.0–3000.0A
0.0A
●
P17.05
Motor speed
0–65535RPM
0 RPM
●
