INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Appendix D
-88-
Function
description
Address
definition
Data meaning
R/W
attribute
Bus voltage
3002H
R
Output voltage
3003H
R
Output current
3004H
R
Running speed
3005H
R
Output power
3006H
R
Output torque
3007H
R
Closed- loop
setting
3008H
R
Closed- loop
feedback
3009H
R
Input IO state
300AH
R
Output IO state
300BH
R
Analog input 1
300CH
R
Analog input 2
300DH
R
Analog input 3
300EH
R
Analog input 4
300FH
R
Read high speed
pulse 1 input
3010H
R
Read high speed
pulse 2 input
3011H
R
Read current step
number of
multi-step speed
3012H
R
External length
value
3013H
R
External counting
value
3014H
R
The set torque
value
3015H
R
VFD identification
code
3016H
R
Fault code
5000H
R
D.2.5 Error message response
Table C-2: Error message response and meaning
Code
Name
Meaning
01H
Illegal command
The command from master cannot be executed. The reason
maybe:
1. This command is only for new version and this version cannot
realize.
