INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Appendix D
-89-
Code
Name
Meaning
2. Slave is in fault state and cannot execute it.
02H
Illegal data
address.
Some of the operation addresses are invalid or not allowed to
access. Especially the combination of the register and the
transmitting bytes are invalid.
03H
Illegal data value
When there are invalid data in the message framed received by
slave.
Note: This error code does not indicate the data value to write
exceed the range, but indicate the message frame is an illegal
frame.
04H
Operation failed
The parameter setting in parameter writing is invalid. For
example, the function input terminal cannot be set repeatedly.
05H
Password error
The password written to the password check address is not
same as the password set by P7.00.
06H
Data frame error
In the frame message sent by the upper computer, the length of
the digital frame is incorrect or the counting of CRC check bit in
RTU is different from the lower computer.
07H
Written not
allowed.
It only happen in write command, the reason maybe:
1. The written data exceeds the parameter range.
2. The parameter should not be modified now.
3. The terminal has already been used.
08H
Parameter cannot
be modified
during running
The modified parameter in the writing of the upper computer
cannot be modified during running.
09H
Password
protection
When the upper computer is writing or reading and the user
password is set without password unlocking, it will report that the
system is locked.
The slave uses function code fields and fault addresses to indicate it is a normal response or some
error occurs (named as objection response). For normal responses, the slave shows corresponding
function codes, digital address or sub-function codes as the response. For objection responses, the
slave returns a code which equals the normal code, but the first byte is logic 1.
For example: when the master sends a message to the slave, requiring it to read a group of address
data of the VFD function codes, there will be following function codes:
0 0 0 0 0 0 1 1 (Hex 03H)
For normal responses, the slave responds the same codes, while for objection responses, it will
return:
1 0 0 0 0 0 1 1 (Hex 83H)
Besides the function codes modification for the objection fault, the slave will respond a byte of
abnormal code which defines the error reason.
When the master receives the response for the objection, in a typical processing, it will send the
message again or modify the corresponding command.
