INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Function parameters
119
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P15.09
PZD9
receiving
motor)
8: Braking torque upper limit (0–2000,1000
corresponds to 100.0% of the rated current of the
motor)
9: Virtual input terminals command
Range:0x000–0x1FF
10: Virtual output terminals command
Range: 0x00–0x0F
11: Voltage setting value (special for V/F
separation )(0–1000,1000 corresponds to 100.0%
the rated voltage of the motor)
12: AO output set value 1 (-1000–1000, 1000
corresponds to 100.0%)
13: AO output set value 2 (-1000–1000, 1000
corresponds to 100.0%)
14–20: Reserved
0
○
P15.10
PZD10
receiving
0
○
P15.11
PZD11
receiving
0
○
P15.12
PZD12
receiving
0
○
P15.13
PZD2 sending
0: Invalid
1: Running frequency (×100,Hz)
2: Setting frequency (×100,Hz)
3: Bus voltage (×10,V)
4: Output voltage (×1,V)
5: Output current (×10,A)
6: Output torque actual value (×10,%)
7: Output power actual value (×10,%)
8: Running rotating speed (×1,RPM)
9: Running linear speed (×1,m/s)
10: Ramp frequency reference
11: Fault code
12: AI1 value (×100,V)
13: AI2 value (×100,V)
14: AI3 value (×100,V)
15: PULSE frequency value (×100,kHz)
16: Terminals input state
17: Terminals output state
18: PID given (×100,%)
19: PID feedback (×100,%)
20: Motor rated torque
21: Control word
0
○
P15.14
PZD3 sending
0
○
P15.15
PZD4 sending
0
○
P15.16
PZD5 sending
0
○
P15.17
PZD6 sending
0
○
P15.18
PZD7 sending
0
○
P15.19
PZD8 sending
0
○
P15.20
PZD9 sending
0
○
P15.21
PZD10
sending
0
○
P15.22
PZD11
sending
0
○
P15.23
PZD12
sending
0
○
