INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Function parameters
121
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P16.03
IP address 3
The format of IP address:
P16.09.P16.10.P16.11.P16.12.
For example: IP address is 192.168.0.1.
0
◎
P16.04
IP address 4
1
◎
P16.05
Subnet mask
1
0–255
Set the subnet mask of Ethernet communication.
The format of IP subnet mask:
P16.13.P16.14.P16.15.P16.16.
For example: The mask is 255.255.255.0.
255
◎
P16.06
Subnet mask
2
255
◎
P16.07
Subnet mask
3
255
◎
P16.08
Subnet mask
4
0
◎
P16.09
Gateway 1
0–255
Set the gateway of Ethernet communication.
192
◎
P16.10
Gateway 2
168
◎
P16.11
Gateway 3
1
◎
P16.12
Gateway 4
1
◎
P17 Group Monitoring function
P17.00
Setting
frequency
Display current set frequency of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.01
Output
frequency
Display current output frequency of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.02
Ramp
reference
frequency
Display current ramp given frequency of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.03
Output voltage
Display current output voltage of the VFD.
Range: 0–1200V
0V
●
P17.04
Output current
Display current output current of the VFD.
Range: 0.0–3000.0A
0.0A
●
P17.05
Motor speed
Display the rotation speed of the motor.
Range: 0–65535RPM
0 RPM
●
P17.06
Torque current
Display current torque current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.07
Exciting
current
Display current exciting current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.08
Motor power
Display current power of the motor.
Setting range: -300.0%–300.0% (the rated
current of the motor)
0.0%
●
