INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Product overview
- 14 -
Function
Specification
Cooling method
Forced air cooling
DC reactor
DC reactors have been built in 380V 18.5–110kW VFD models
as standard configuration.
DC reactors are optional parts for 380V 132kW and higher
models and for 660V models and can be externally connected.
Braking unit
Braking units have been built in 380V 110kW and lower VFD
models as standard configuration. Braking units are optional
parts for 660V models and can be externally connected.
EMC filter
C3 filters are optional parts and can be built in VFDs.
If C3 filters are required, connect the jumper J10. After C3 filters
are configured, the VFDs can meet IEC61800-3 C3
requirements.
External filters can be configured to meet IEC61800-3 C2
requirements.
Table 3.2 Dedicated functions
Function
Control method
Dedicated
function
Mode
V/F
SVC
VC
Brake control
Brake control
√
√
√
Restart after braking
√
√
√
Brake feedback
√
√
√
Zero position detection
√
√
√
Current verification
√
Torque verification
√
√
Brake slip verification
√
Speed deviation detection
√
√
√
Jogging
√
√
√
Set frequency exception
protection
√
√
√
Torque control
Torque control
√
√
Pre torque
√
√
Conical motor
Conical motor control
√
Light load speed boost
Simplified speed boost mode
√
√
Constant power speed boost
√
Constant power speed limit
√
Stepped speed limit
√
Safety function
STO
√
√
√
