INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Product overview
- 13 -
Function
Specification
RO2A NO, RO2B NC, RO2C common terminal
Contact capacity: 3A/250VAC, 1A/30VDC
Extension
interface
Three extension interfaces: SLOT1, SLOT2, SLOT3
Extensible PG card, programmable extension card,
communication card, I/O card, and so on
Note:
 You can install extension cards (optional) for 1.5–5.5kW VFD
models and you are recommended to install them at slot 2.
 I/O extension card 2 has been installed at slot 3 for 7.5kW and
higher VFD models as standard configuration.
I/O
extension
card 2
Relay output
Two programmable relay outputs
RO3A NO, RO3C common terminal
RO4A NO, RO4C common terminal
Contact capacity: 3A/250VAC, 1A/30VDC
Digital input
Four regular inputs, supporting PTC input during DC power
supply, and the PTC acting at 2.5kΩ, but not supporting PTC
input during AC power supply;
Internal impedance: 6.6kΩ;
Max. input frequency: 1kHz;
Supporting the internal power 24V;
Supporting the voltage input of external power
(-20%)24–48VDC(+10%) and (-10%)24–48VAC(+10%);
Bidirectional input terminals, simultaneously supporting NPN and
PNP connection methods
PT100 input
Independent PT100 and PT1000 input:
Resolution: 1°C
Range: -20°C–150°C
Detection precision: ±3°C
Supporting offline protection
PT1000 input
Other
Installation
method
Wall mounting, floor mounting, or flange mounting
Temperature of
running
environment
-10–50°C
Derating is required if the ambient temperature exceeds 40°C.
IP rating
IP20
Pollution degree
Degree 2
