INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Dimensional drawings
-495-
W1
W2
H1 H2
W3
D1
Figure C.7 380V 45–75kW VFD wall mounting diagram
VFD model
Outline dimensions
(mm)
Hole distance (mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
W3
H2
45kW–75kW
282
560
258
160
226
542
9
M8
25
29
W1
D1
W2
H1 H2
Figure C.8 380V 90–110kW VFD wall mounting diagram
VFD model
Outline dimensions
(mm)
Hole distance
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
H2
90kW–110kW
338
554
330
200
535
10
M8
41
52
