Goodrive350-19 series VFD Dimensional drawings
-498-
W1
H1
D1
W2
H2
98.0
D2
W2
W3W4
H4
H2
H3
Figure C.12 380V 90–110kW VFD flange installation diagram
VFD
model
Outline
dimensions
(mm)
Mount
dimensions
(mm)
Hole distance
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
H2
D2
H3
W4
H4
90kW–
110kW
418.5
600
330
389.5
370
149.5
559
14.2
108.5
10
M8
41
52
W1
D1
W2 W2
D2
H2H1
W4
W3
W2
W2
H4
H2
H3
Figure C.13 380V 132–200kW VFD flange installation diagram
VFD model
Outline
dimensions
(mm)
Mount
dimensions
(mm)
Hole distance
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
H2
D2
W3
H3
W4
H4
132kW–200kW
500
870
360
180
850
178.5
480
796
60
37
11
M10
85
110
