Goodrive350-19 series VFD Dimensional drawings
-499-
C.5.3 Floor installation dimensions
W4
W2
W2
H1
H2
D1
W1
W3
D2
D2
3- ø13.0
6- ø12.0
Figure C.14 380V 220–315kW VFD floor installation diagram
VFD model
Outline
dimensions (mm)
Mount dimensions
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W4
W2
W3
H2
D2
220kW–315kW
750
1410
380
680
230
714
1390
150
13/12
M12/
M10
135
165
