Goodrive350-19 series VFD Dimensional drawings
-504-
W1
W2
W2
H1
H2
3- ø22.0
D1
D2
D2
W3
6- ø12.0
Figure C.22 660V 400–630kW VFD floor installation diagram
VFD model
Outline
dimensions
(mm)
Mount dimensions
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
W3
H2
D2
400kW–630kW
620
1700
560
230
572
1678
240
22/12
M20/M10
350
407
